In the previous blog post, we discussed how to configure a simple OAuth2 authentication. However, our implementation has a major flaw in it: we are using an in-memory token store.
In-Memory token stores should be used only during development or whether your application has a single server, as you can’t easily share them between nodes and, in case of a server restart, you will lose all access tokens in it.
Spring-security-oauth2 already has built-in support for JDBC and JWT. However, if you need to save your tokens somewhere else, you have to create your own spring security token store. Unfortunately, implementing such a thing is not a trivial task, and I hope the following recipe will save you a couple hours of work.
Let’s start by creating the two entities responsible for storing your access and refresh token, and their respective repositories:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 |
import lombok.Data; import org.springframework.data.annotation.Id; import org.springframework.data.couchbase.core.mapping.Document; import org.springframework.security.oauth2.common.OAuth2AccessToken; import org.springframework.security.oauth2.provider.OAuth2Authentication; @Document @Data public class CouchbaseAccessToken { @Id private String id; private String tokenId; private OAuth2AccessToken token; private String authenticationId; private String username; private String clientId; private String authentication; private String refreshToken; public OAuth2Authentication getAuthentication() { return SerializableObjectConverter.deserialize(authentication); } public void setAuthentication(OAuth2Authentication authentication) { this.authentication = SerializableObjectConverter.serialize(authentication); } } |
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 |
@N1qlPrimaryIndexed @ViewIndexed(designDoc = "couchbaseAccessToken") public interface CouchbaseAccessTokenRepository extends CouchbasePagingAndSortingRepository<CouchbaseAccessToken, String> { List<CouchbaseAccessToken> findByClientId(String clientId); List<CouchbaseAccessToken> findByClientIdAndUsername(String clientId, String username); Optional<CouchbaseAccessToken> findByTokenId(String tokenId); Optional<CouchbaseAccessToken> findByRefreshToken(String refreshToken); Optional<CouchbaseAccessToken> findByAuthenticationId(String authenticationId); } |
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 |
import lombok.Data; import org.springframework.data.annotation.Id; import org.springframework.data.couchbase.core.mapping.Document; import org.springframework.security.oauth2.common.OAuth2RefreshToken; import org.springframework.security.oauth2.provider.OAuth2Authentication; @Document @Data public class CouchbaseRefreshToken { @Id private String id; private String tokenId; private OAuth2RefreshToken token; private String authentication; public OAuth2Authentication getAuthentication() { return SerializableObjectConverter.deserialize(authentication); } public void setAuthentication(OAuth2Authentication authentication) { this.authentication = SerializableObjectConverter.serialize(authentication); } } |
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 |
import org.springframework.data.couchbase.core.query.N1qlPrimaryIndexed; import org.springframework.data.couchbase.core.query.ViewIndexed; import org.springframework.data.couchbase.repository.CouchbasePagingAndSortingRepository; import java.util.List; import java.util.Optional; @N1qlPrimaryIndexed @ViewIndexed(designDoc = "couchbaseAccessToken") public interface CouchbaseAccessTokenRepository extends CouchbasePagingAndSortingRepository<CouchbaseAccessToken, String> { List<CouchbaseAccessToken> findByClientId(String clientId); List<CouchbaseAccessToken> findByClientIdAndUsername(String clientId, String username); Optional<CouchbaseAccessToken> findByTokenId(String tokenId); Optional<CouchbaseAccessToken> findByRefreshToken(String refreshToken); Optional<CouchbaseAccessToken> findByAuthenticationId(String authenticationId); } |
Note that OAuth2Authentication is an interface, so I have no option other than serializing the object to store it in the database. Here is the class responsible for serializing/deserializing it:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 |
public class SerializableObjectConverter { public static String serialize(OAuth2Authentication object) { try { byte[] bytes = SerializationUtils.serialize(object); return Base64.encodeBase64String(bytes); } catch(Exception e) { e.printStackTrace(); throw e; } } public static OAuth2Authentication deserialize(String encodedObject) { try { byte[] bytes = Base64.decodeBase64(encodedObject); return (OAuth2Authentication) SerializationUtils.deserialize(bytes); } catch(Exception e) { e.printStackTrace(); throw e; } } |
Now, we can finally create our custom spring oauth2 token store. To do that, all we need is to implement the long list of methods of the org.springframework.security.oauth2.provider.token.TokenStore:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 |
import org.springframework.security.oauth2.common.OAuth2AccessToken; import org.springframework.security.oauth2.common.OAuth2RefreshToken; import org.springframework.security.oauth2.provider.OAuth2Authentication; import org.springframework.security.oauth2.provider.token.AuthenticationKeyGenerator; import org.springframework.security.oauth2.provider.token.DefaultAuthenticationKeyGenerator; import org.springframework.security.oauth2.provider.token.TokenStore; import java.io.UnsupportedEncodingException; import java.math.BigInteger; import java.security.MessageDigest; import java.security.NoSuchAlgorithmException; import java.util.*; public class CouchbaseTokenStore implements TokenStore { private CouchbaseAccessTokenRepository cbAccessTokenRepository; private CouchbaseRefreshTokenRepository cbRefreshTokenRepository; public CouchbaseTokenStore(CouchbaseAccessTokenRepository cbAccessTokenRepository, CouchbaseRefreshTokenRepository cbRefreshTokenRepository){ this.cbAccessTokenRepository = cbAccessTokenRepository; this.cbRefreshTokenRepository = cbRefreshTokenRepository; } private AuthenticationKeyGenerator authenticationKeyGenerator = new DefaultAuthenticationKeyGenerator(); @Override public OAuth2Authentication readAuthentication(OAuth2AccessToken accessToken) { return readAuthentication(accessToken.getValue()); } @Override public OAuth2Authentication readAuthentication(String token) { Optional<CouchbaseAccessToken> accessToken = cbAccessTokenRepository.findByTokenId(extractTokenKey(token)); if (accessToken.isPresent()) { return accessToken.get().getAuthentication(); } return null; } @Override public void storeAccessToken(OAuth2AccessToken accessToken, OAuth2Authentication authentication) { String refreshToken = null; if (accessToken.getRefreshToken() != null) { refreshToken = accessToken.getRefreshToken().getValue(); } if (readAccessToken(accessToken.getValue()) != null) { this.removeAccessToken(accessToken); } CouchbaseAccessToken cat = new CouchbaseAccessToken(); cat.setId(UUID.randomUUID().toString()+UUID.randomUUID().toString()); cat.setTokenId(extractTokenKey(accessToken.getValue())); cat.setToken(accessToken); cat.setAuthenticationId(authenticationKeyGenerator.extractKey(authentication)); cat.setUsername(authentication.isClientOnly() ? null : authentication.getName()); cat.setClientId(authentication.getOAuth2Request().getClientId()); cat.setAuthentication(authentication); cat.setRefreshToken(extractTokenKey(refreshToken)); cbAccessTokenRepository.save(cat); } @Override public OAuth2AccessToken readAccessToken(String tokenValue) { Optional<CouchbaseAccessToken> accessToken = cbAccessTokenRepository.findByTokenId(extractTokenKey(tokenValue)); if (accessToken.isPresent()) { return accessToken.get().getToken(); } return null; } @Override public void removeAccessToken(OAuth2AccessToken oAuth2AccessToken) { Optional<CouchbaseAccessToken> accessToken = cbAccessTokenRepository.findByTokenId(extractTokenKey(oAuth2AccessToken.getValue())); if (accessToken.isPresent()) { cbAccessTokenRepository.delete(accessToken.get()); } } @Override public void storeRefreshToken(OAuth2RefreshToken refreshToken, OAuth2Authentication authentication) { CouchbaseRefreshToken crt = new CouchbaseRefreshToken(); crt.setId(UUID.randomUUID().toString()+UUID.randomUUID().toString()); crt.setTokenId(extractTokenKey(refreshToken.getValue())); crt.setToken(refreshToken); crt.setAuthentication(authentication); cbRefreshTokenRepository.save(crt); } @Override public OAuth2RefreshToken readRefreshToken(String tokenValue) { Optional<CouchbaseRefreshToken> refreshToken = cbRefreshTokenRepository.findByTokenId(extractTokenKey(tokenValue)); return refreshToken.isPresent()? refreshToken.get().getToken() :null; } @Override public OAuth2Authentication readAuthenticationForRefreshToken(OAuth2RefreshToken refreshToken) { Optional<CouchbaseRefreshToken> rtk = cbRefreshTokenRepository.findByTokenId(extractTokenKey(refreshToken.getValue())); return rtk.isPresent()? rtk.get().getAuthentication() :null; } @Override public void removeRefreshToken(OAuth2RefreshToken refreshToken) { Optional<CouchbaseRefreshToken> rtk = cbRefreshTokenRepository.findByTokenId(extractTokenKey(refreshToken.getValue())); if (rtk.isPresent()) { cbRefreshTokenRepository.delete(rtk.get()); } } @Override public void removeAccessTokenUsingRefreshToken(OAuth2RefreshToken refreshToken) { Optional<CouchbaseAccessToken> token = cbAccessTokenRepository.findByRefreshToken(extractTokenKey(refreshToken.getValue())); if(token.isPresent()){ cbAccessTokenRepository.delete(token.get()); } } @Override public OAuth2AccessToken getAccessToken(OAuth2Authentication authentication) { OAuth2AccessToken accessToken = null; String authenticationId = authenticationKeyGenerator.extractKey(authentication); Optional<CouchbaseAccessToken> token = cbAccessTokenRepository.findByAuthenticationId(authenticationId); if(token.isPresent()) { accessToken = token.get().getToken(); if(accessToken != null && !authenticationId.equals(this.authenticationKeyGenerator.extractKey(this.readAuthentication(accessToken)))) { this.removeAccessToken(accessToken); this.storeAccessToken(accessToken, authentication); } } return accessToken; } @Override public Collection<OAuth2AccessToken> findTokensByClientIdAndUserName(String clientId, String userName) { Collection<OAuth2AccessToken> tokens = new ArrayList<OAuth2AccessToken>(); List<CouchbaseAccessToken> result = cbAccessTokenRepository.findByClientIdAndUsername(clientId, userName); result.forEach(e-> tokens.add(e.getToken())); return tokens; } @Override public Collection<OAuth2AccessToken> findTokensByClientId(String clientId) { Collection<OAuth2AccessToken> tokens = new ArrayList<OAuth2AccessToken>(); List<CouchbaseAccessToken> result = cbAccessTokenRepository.findByClientId(clientId); result.forEach(e-> tokens.add(e.getToken())); return tokens; } private String extractTokenKey(String value) { if(value == null) { return null; } else { MessageDigest digest; try { digest = MessageDigest.getInstance("MD5"); } catch (NoSuchAlgorithmException var5) { throw new IllegalStateException("MD5 algorithm not available. Fatal (should be in the JDK)."); } try { byte[] e = digest.digest(value.getBytes("UTF-8")); return String.format("%032x", new Object[]{new BigInteger(1, e)}); } catch (UnsupportedEncodingException var4) { throw new IllegalStateException("UTF-8 encoding not available. Fatal (should be in the JDK)."); } } } } |
Finally, we can slightly change our SecurityConfig class, which we have created in the previous article. It will return now an instance of CouchbaseTokenStore instead of InMemoryTokenStore:
|
1 2 3 4 5 6 7 8 9 10 11 |
@Autowired private CouchbaseAccessTokenRepository couchbaseAccessTokenRepository; @Autowired private CouchbaseRefreshTokenRepository couchbaseRefreshTokenRepository; @Bean public TokenStore tokenStore() { return new CouchbaseTokenStore(couchbaseAccessTokenRepository, couchbaseRefreshTokenRepository); } |
Here is the complete version of the SecurityConfig class:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 |
@Configuration @EnableWebMvc public class SecurityConfig extends WebSecurityConfigurerAdapter { @Autowired private CustomUserDetailsService customUserDetailsService; @Autowired private CouchbaseAccessTokenRepository couchbaseAccessTokenRepository; @Autowired private CouchbaseRefreshTokenRepository couchbaseRefreshTokenRepository; @Autowired public void globalUserDetails(AuthenticationManagerBuilder auth) throws Exception { auth.userDetailsService(customUserDetailsService) .passwordEncoder(encoder()); } @Override public void configure( WebSecurity web ) throws Exception { web.ignoring().antMatchers( HttpMethod.OPTIONS, "/**" ); } @Override protected void configure(HttpSecurity http) throws Exception { http .csrf().disable() .authorizeRequests() .antMatchers("/oauth/token").permitAll() .antMatchers("/api-docs/**").permitAll() .anyRequest().authenticated() .and().anonymous().disable(); } @Bean public TokenStore tokenStore() { return new CouchbaseTokenStore(couchbaseAccessTokenRepository, couchbaseRefreshTokenRepository); } @Bean public PasswordEncoder encoder(){ return NoOpPasswordEncoder.getInstance(); } @Bean public FilterRegistrationBean corsFilter() { UrlBasedCorsConfigurationSource source = new UrlBasedCorsConfigurationSource(); CorsConfiguration config = new CorsConfiguration(); config.setAllowCredentials(true); config.addAllowedOrigin("*"); config.addAllowedHeader("*"); config.addAllowedMethod("*"); source.registerCorsConfiguration("/**", config); FilterRegistrationBean bean = new FilterRegistrationBean(new CorsFilter(source)); bean.setOrder(0); return bean; } @Bean @Override public AuthenticationManager authenticationManagerBean() throws Exception { return super.authenticationManagerBean(); } } |
Well Done! That is all we had to do.
Your access token will look like the following in your database:
|
1 2 |
SELECT * from test where _class = 'com.bc.quicktask.standalone.model.CouchbaseAccessToken' |
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 |
[ { "YOUR_BUCKET_NAME": { "_class": "com.bc.quicktask.standalone.model.CouchbaseAccessToken", "authentication": "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", "authenticationId": "202d6940ebd428bbe2098530c8de3958", "clientId": "myclient", "refreshToken": "7613ffc6480ae83beb8f0988ef9ecfcf", "token": { "_class": "org.springframework.security.oauth2.common.DefaultOAuth2AccessToken", "additionalInformation": {}, "expiration": 1537420023432, "refreshToken": { "_class": "org.springframework.security.oauth2.common.DefaultExpiringOAuth2RefreshToken", "expiration": 1537420023421, "value": "c44db735-403e-49d6-8a22-cfe0e29f21d3" }, "scope": [ "trust", "read", "write" ], "tokenType": "bearer", "value": "7759804c-e1c6-4d63-9520-8737f5b46dbf" }, "tokenId": "12b6bd9de380e1dfab348f4c15abb805", "username": "myuser" } } ] |
I have used caelwinner’s project as a reference, here is my special thanks to him.
If you have any questions, feel free to tweet me at @deniswsrosa
